WPOC.HAY817C

Description:

Hayward X-Stream CC100, open w/molded gasket

USA Inches Metric
Diameter 8 15/16 227 mm
LENGTH 17 3/8 441 mm
Top Hole 4 " 102 mm
Bottom Hole 4 " 102 mm
MEDIA WEIGHT 135.6240 g/m^2 4 oz/yd^2
MEDIA SQ. FEET 100 sq ft 9.2903 sq m
MANUFACTURER PART #’S CCX1000-RE, 817-0100N/P
CASE QUANTITY 1
UPC CODE EACH 849373016849
UPC CODE CASE
REPLACES
PLEATCO Unicel Filbur
PXST100 C-8311 FC-1285
Features:
  • Proudly made in the USA Crafted with American quality and precision
  • Strong coresInjection-molded cores made from 100% virgin ABS or PP
  • Rugged point-bonded construction Patterned design allows for even loading
  • Break-resistant bands Strategically placed to support the media and maintain pleat spacing
  • Symmetric core openings Provide even filter loading during use
  • Robust end caps Made from time-tested chlorine and mildew-resistant urethane system
  • Flawless fit Precisely engineered to meet pool and spa specifications
  • Quick check Unique OnCore part number for easy identification
